NOCPIX Mate H50R Thermal Clip-On

The NOCPIX Mate H50R is a thermal clip-on attachment that fits in front of a day scope. It has a 640 × 512 12μm sensor, a 50mm F1.0 lens and an integrated laser rangefinder to 1,200m.

Key Features

• Clip-On Design – fits in front of your day scope, with an M52 adapter interface
• Magic Zoom – supplied accessory that adjusts the thermal image and interface as you change your day scope's magnification
• Shutterless Imaging – no shutter pauses and no manual calibration
• Integrated LRF – laser rangefinder to 1,200m with ballistic calculation
• 18650 Batteries – 3 supplied with a charger, up to 4 hours
• Recording and Connectivity – recoil-activated video, gallery playback, Wi-Fi and app connection, N-Link and remote control
• Built for the Field – IP67 rated, 64GB of storage

Specification

• Brand: NOCPIX
• Model: Mate H50R
• SKU: NPCLIP-MATE-H50R
• Thermal Sensor: 640 × 512, 12μm
• NETD: ≤15mK
• Frame Rate: 60Hz
• Objective Lens: 50mm, F1.0
• Field of View: 8.6° × 6.6°
• Detection Range: up to 2,600m against a 1.7m × 0.5m target (manufacturer's figure)
• Display: 0.49 inch AMOLED, 1920 × 1080
• Laser Rangefinder: up to 1,200m
• Battery: replaceable 18650 batteries
• Battery Life: up to 4 hours at 22°C
• Storage: 64GB
• Weight: 467g with battery
• Dimensions: 120 × 92 × 76mm
• Ingress Protection: IP67
• Operating Temperature: −20 to +50°C
• In Box: MATE Series Thermal Imaging Attachment; Remote Control Accessories; Magic Zoom; 3 x 18650 battery; Battery charger; Type-C cable; Heated target for zeroing x10; Lens cloth; Quick start guide; Portable bag
